Sokkia SHC5000 Data Collector

Sokkia SHC5000

Meet the SHC 5000 – featuring the advantages of both a tablet PC and a rugged handheld computer, without the disadvantages of either.


The SHC 5000 is a data collection powerhouse with massive screen real estate, yet it still feels like a compact handheld at the end of the long work day.


  • 7 inch sunlight readable display
  • Mil-STD 810G and IP68 certified
  • 8MP rear, 2MP front digital cameras
  • 4G LTE cellular modem, optional
  • Internal GPS, 2 to 5 meter accuracy
  • Integrated Bluetooth and Wi-Fi
  • Extended Range Bluetooth



Forensic Mapping
Forensic CAD
CSI Mapping
Data Collector
Forensic Mapping Training
Total Station

Get the SHC5000 data collector for forensic mapping by crash and crime scene investigators brochure Here



Forensic Mapping
Forensic CAD
CSI Mapping
Data Collector
Forensic Mapping Training
Total Station

Sokkia SHC5000 GEO

 or GEO CELL Models with

Extended Range Bluetooth
Internal GSM 4G LTE modem
RAM / 64GB or Optional 128 GB eMMC Storage
Windows 8.1/10 Professional (Embedded)
8.5” L x 5.4” W x 1.375” D
Full feature usage in either portrait to landscape orientations
Front and Rear facing digital cameras

Sokkia SHC500

Sokkia SHC500

Built and tested to the most rigorous of standards, the SHC500 was designed to be your reliable companion, wherever your scene takes you.

This tough handheld runs smoothly in everything from freezing cold to blistering heat.

Carrying an IP68 rating and tested to

 MIL-STD-810G for water, humidity, sand and dust, vibration, altitude, shock, and temperature, the SHC500 can handle just about anything you throw at it.

Active viewing area: 4.3 (109 mm)

WVGA LCD TFT (800x480)

High outdoor visibility back lit LCD Support for portrait or landscape orientation

Scratch resistant Glass


Internal GPS 2-5m accuracy - GEO Model


3.5G cellular module - GEO CELL Model

Forensic Mapping
Forensic CAD
CSI Mapping
Data Collector
Forensic Mapping Training
Total Station

Get the SHC500 data collector for forensic mapping by crash and crime scene investigators brochure Here

Forensic Mapping
Forensic CAD
CSI Mapping
Data Collector
Forensic Mapping Training
Total Station

Sokkia SHC500 Standard, GEO, or GEO CELL
Microsoft® Windows Embedded Handheld 6.5
512 MB RAM, 8 GB Flash Storage
1 user accessible Micro SD/SDHC slot,

supporting up to 32GB of storage
Built-in wireless Bluetooth® and WiFi
23 Control buttons, with Numeric input,

9-pin serial port
Accessible, rechargeable and hot swappable batteries
5 Megapixel camera

Juniper Systems Allegro2

Juniper Systems Allegro2

From the carefully selected, textured buttons which click with just the right amount of feedback, to the slope of the contours that mimic so perfectly the shape of the human hand, every last detail of the Allegro 2™ was painstakingly honed to provide you with unparalleled speed and precision.

The Allegro 2 maintains Juniper Systems’ reputation for reliability, while offering new features and advancements to make data collection easier than ever.

The Allegro Field PC® line has long been favored for applications with high-volume data collection, and the Allegro 2 is no different, except for the fact that it’s only gotten better. With a newly-designed QWERTY + numeric keyboard, the Allegro 2 features large, glove-friendly buttons, allowing for faster, non-visual (if you’re into that) data entry. It’s had a massive upgrade in battery power, display visibility, touchscreen, connectivity…oh, pretty much everything. We give you…the Allegro 2, designed for the data-intensive.

  • Active viewing area: 4.2" (107 mm)
  • TFT VGA(640x480) Landscape Display
  • High visibility back lit LCD
  • IP68 waterproof and dust proof
  • Operating temperature: -22F to 140F
  • (-30C to 60C),

Note: Bluetooth® wireless technology

is rated to –4F (–20C)

  • Storage temperature: -22F to 158F
  • (–30C to 70C)
  • Shockproof: multiple drops from                    4'(1.2 m) onto concrete

Forensic Mapping
Forensic CAD
CSI Mapping
Data Collector
Field PC
Evidence
Forensic
Total Station

Get the Allegro2 data collector for forensic mapping by accident and crime scene investigators brochure Here


Microsoft® Windows Embedded Handheld 512MB RAM

8GB flash storage

User-accessible micro SD/SDHC slot

CSI Mapping
Forensic Mapping
Accident Reconstruction
Sokkia
Evidence Recorder



  • COM1, RS-232C 9-pin D connector with 5VDC power output on pin 9 software-enabled
  • USB host (Full A), USB client (Micro B)
  • 12, 24VDC input, 10-36V unregulated
  • 3.5 mm audio jack, supports speaker/ microphone or stereo output (pin detect)
  • I/O module OEM configurable/customizable
  • I/O docking ports for charging and USB communication


Allegro2 has 3 models to choose from:


Standard model includes:

Wi-Fi and Bluetooth


Geo Model includes:

Wi-Fi and Bluetooth

GPS + GLONASS GNSS

SMP Camera


Geo Cell Model includes

GMS Modem

Wi-Fi and Bluetooth

GPS + GLONASS GNSS

SMP Camera
